Diamond Wire Rope Saw (Stone & Concrete)

Marble Slab Cutting Multi-Wire Saw (Fine Beads)

Specially designed for high-efficiency cutting of large marble slabs using combination wire saws and multi-wire stone cutting machines. Utilising fine-diameter beads (4.3–8.3 mm), it produces narrow kerfs, high yield rates and a flat, smooth surface, making it suitable for high-volume slab processing.

Request a Quote

Overview

Product overview

1. Bead outer diameter specifications: 8.3 mm, 7.3 mm, 6.3 mm, 5.3 mm, 4.3 mm. 2. Number of beads per metre: 37 beads per metre across the range. 3. Fixing method: Injection-moulded (P) or spring-loaded (S), ensuring the beads remain securely in place during high-speed operation. 4. Bead manufacturing process: Laser welding; the beads have a relatively soft body, high sharpness and provide a smooth, effortless cut. 5. Steel cable core: Fine-diameter, high-strength steel cable with good flexibility, suitable for guide wheels on multi-wire cutting machines. 6. Applications: Bulk cutting of large marble slabs to increase output and yield.

Specification

Technical specification

Technical specifications
Specification	Value
Bead sizes	10.5mm, 11.5mm (customizable per customer machine)
Beads per meter	37-40
Fixing method	Rubber (R) / Spring (S) / Injection-Molded / Plastic (P) optional
Applicable materials	basalt, diabase, black galaxy, etc.
Matrix type	high‑wear thick
Diamond type	high‑density coarse
